Deye BOS-W (AS, AF, LATAM) Solar Storage System | 5.12kWh Commercial Grade LiFePO₄ Module

  • Advanced Safety: Protects against over-charge, over-discharge, over-current, and extreme temperatures with LiFePO₄ battery technology
  • High Performance: Temperature range (-20°C to 55°C), ≥6000 cycles
  • Flexible Configuration: Parallel connections, USB, and remote upgrades
  • Reliable Storage: Low self-discharge for up to 6 months without charging
  • Scalable Energy: Modular design from 25.6 kWh to 87.04 kWh
  • Durable Build: Rack-mounted installation with IP20 protection
  • User-Friendly: CAN2.0/RS485 communication ports and status indicators
  • Suitable Deye Inverter Model:
      • SUN-30K-SG01HP3-EU-BM3
      • SUN-40K/50K-SG01HP3-EU-BM4
      • SUN-60K-SG02HP3-EU-EM4
      • SUN-80K-SG02HP3-EU-EM6
SKU: BOS-W (AS, AF, LATAM)Categories: Small-Scale C&I ESS
Contact Us

Description

Small-Scale C&I Energy Storage Solution

Introducing our Small-Scale Commercial and Industrial (C&I) Energy Storage Solution, featuring models SUN-50K-SG01HP3-EU-BM4, SUN-80K-SG02HP3-EU-EM6, and BOS-W. It’s designed to meet diverse energy needs with outstanding performance.

Parameter Value
Main Parameters Cell Chemistry LiFePO₄
Module Energy 5.12 kWh
Module Voltage 51.2 V
Module Capacity 100 Ah
System Usable Energy (kWh) Up to 78.33 kWh (depending on series configuration)
System Models BOS-W25 25.6 kWh (5 modules in series)
BOS-W40 40.96 kWh (8 modules in series)
BOS-W60 61.44 kWh (12 modules in series)
BOS-W85 87.04 kWh (17 modules in series)
Physical & Performance Specifications Working Temperature -20°C to 55°C
Storage Temperature 0-35°C
Cycle Life ≥6000 cycles (with 70% End of Life capacity)
Recommended Depth of Discharge 90%
Rated DC Power 25.6 kW to 87.04 kW
Charge/Discharge Current Recommend 50 A; maximum peak discharge 125 A (for 2 minutes at 25°C)
Installation Rack-mounted
Dimensions (W × D × H) Vary based on model (BOS-W85: 1060 × 602 × 1629 mm)
Weight Up to 883 kg
IP Rating IP20
Communication Port CAN2.0/RS485
Warranty 5 years
Certifications UN38.3

Key Features

  • Practicality & Universal Compatibility: Offers 100% unbalanced output, enables AC coupling to retrofit existing solar systems, and has dual independent battery circuits.
  • Versatile & High-Performance: Comes with a TOU function (six time periods for battery charging/discharging), is diesel generator-ready, and supports VSG application.
  • Safe & Reliable: Utilizes LFP batteries with low self-discharge (up to 6 months without charging).
  • Smart Protection: Shields against over-discharge/charge, current issues, and extreme temps, while auto-managing charge, discharge, and cell balancing.
  • Flexible Expansion: Supports multiple battery modules in parallel, USB, and remote upgrades.
  • No Memory Effect: Performs excellently with shallow charge and discharge cycles.
  • Wide Temp Range: Operates in temperatures from -20°C to 55°C.
  • High Performance: Delivers superior discharge and boasts a cycle life of over 6000 times.

Download

Deye BOS-W Datasheet Russian

Deye BOS-W User Manual EN

Deye BOS-W+50K & 80K Energy Storage Solution EN

Certificate

Statement

DEYE Statement on Battery Expansion and Insulation Fault
