| Model | MS-ACC60-2 | MS-ACC80-2 | MS-ACC120-2 | MS-ACC160-2 |
| Power lnput | ||||
| Input Rating | 400Vac±10%, 3-Phase, 50/60 Hz, L1+L2+L3+N+PE | |||
| Power Factor | 0.98 | |||
| Current THD | ≤5% | |||
| Max.Efficiency | 96.5% | |||
| Power Output | ||||
| Output Interface | CCS2*2 | |||
| Output Voltage | 150-1000 Vdc | |||
| DC Output Current | 200A max. | 200A max. | 250A max. | 250A max. |
| DC Output Power | 60kW max. | 80kW max. | 120kW max. | 160kW max. |
| Distribution Stategy | Intelligent Power Distribution | |||
| User lnterface & Control | ||||
| Display | 10.1-inch Touch Screen | |||
| Support Language | English, French, Other Languages Available Upon Request | |||
| Push Buttons | Emergency Stop Button | |||
| Authentication | RFID Card,APP(Remote Start&QR Code),Credit Card,Plug&Charge | |||
| Communication | ||||
| Network Interface | 4G, Wi-Fi, Ethernet | |||
| Protocol Charge & Backend | OCPP 1.6J OCPP 2.0.1 (Upgradable) |
|||
| Environmental | ||||
| Operating Temperature | -30℃-55℃ | |||
| Storage Temperature | -40℃-70℃ | |||
| Humidity | 5%~95% No Condensation | |||
| Altitude | ≤2000m（Derating From 2000m） | |||
| Noise | ≤65dB@1m | |||
| Mechanical | ||||
| Ingress Protection | IP55 | |||
| Enclosure Protection | IK10 | |||
| Cooling | Forced Air Cooling | |||
| Charging Cable Length | 5m (Standard)/7m(Optional) | |||
| Dimensions (W*H*D) / Weight | 873*1935*600mm/Approx. ≤430kg | |||
| Installation | Ground Mounting | |||
| Compliance | IEC61851-1,IEC61851-21-2,IEC61851-23,IEC61851-24,LVD2014/35/EU,RED2014/53/EU | |||
| Certification | CE ,CB | |||
