RW-F16 (AS, AF, LATAM) Flexible Residential Energy Storage Solution

  • Smart Monitoring: Real-time status updates via master LED indicator
  • High Scalability: Expandable capacity up to 512 kWh with multiple units
  • Robust Charging: Supports 160 A charge rate and 300 A peak discharge
  • Environmental Usability: Operates effectively from -20°C to 55°C
  • User-Friendly Installation: Wall-mounted or floor-mounted
  • Warranty & Support: 5-year warranty (10 years extendable)
  • Eco-Friendly Materials: Non-toxic, pollution-free materials
  • Suitable Deye Inverter Model:
      • SUN-7/7.6/8/10K-5G05LP1-EU-SM2
      • SUN-12/14/16K-SGO1LP1-EU
      • SUN-5/6/8/10/12K-SG04LP3-EU
      • SUN-3/4/5/6/8/10/12K-SG05LP3-EU-SM2
      • SUN-14/15/16/18/20K-SG05LP3-EU-SM2
SKU: RW-F16 (AS, AF, LATAM)Categories: Low Voltage Series (LV)
Contact Us

Description

Residential Energy Storage Solution: RW-F16 Battery

The RW-F16 battery is a stellar part of our residential energy storage solution, ideal for homeowners seeking reliable and efficient energy management.

Specification Detail
Model RW – F16
Battery Chemistry LiFePO₄
Capacity 314 Ah
Nominal Voltage 51.2 V
Usable Energy 14.4 kWh (90% Depth of Discharge)
Charge/Discharge Current – Maximum Continuous 160 A
Charge/Discharge Current – Peak 300 A (10 seconds)
Dimensions 480 x 830 x 235 mm
Weight Approximately 122 kg
IP Rating IP20 (suitable for indoor use)
Operating Temperature Range – Charge 0°C to 55°C
Operating Temperature Range – Discharge -20°C to 55°C
Relative Humidity 95% (maximum)
Installation Wall – mounted or floor – mounted
Warranty Period 5 – year warranty (10 years extendable)
Certification UN38.3, MSDS

Key Features:

  • Top-Notch Safety: It adopts the safest LiFePO₄ battery chemistry and is equipped with an Intelligent BMS. This ensures secure operation, giving you peace of mind.
  • Impressive Output & Energy: Boasting a maximum 8kW output power and 14.4kWh usable energy (with 90% depth of discharge), it meets substantial home energy needs.
  • External Power Support: Enables external power activation, effectively preventing battery suspension and ensuring consistent energy supply.
  • Flexible Application & Expansion: Comes with built-in 10A constant current limited charging, compatible with many inverter brands. Also, it allows up to 32 units in parallel for flexible expansion.
  • Easy Maintenance: Allows over-discharge direct recharge, simplifying upkeep.

With dimensions of 480 x 830 x 235 mm, weighing approx 122 kg, and an IP20 rating for indoor use, plus a 5-year warranty (extendable to 10 years) and certifications like UN38.3 and MSDS, the RW-F16 is a trustworthy choice for your home energy storage.

Download

Deye RW-F16+SUN-20K-SG05LP3-EU-SM2 Energy Storage Solution EN

Deye RW-F16+SUN-20K-SG05LP3-EU-SM2 Energy Storage Solution French

Deye RW-F16+SUN-20K-SG05LP3-EU-SM2 Energy Storage Solution Russian

Deye ESS User Manual RW-F16 EU (EN) V04

Deye ESS User Manual RW-F16 EU (DE+EN) With Wheel V01

Certificate

CE-EMC_RW-F16_DSS_SZEM2502001384Ver_CE

CB_IEC 62619_DSS_FI-65572

Statement

DEYE Statement on Battery Expansion and Insulation Fault
