RW-L5.1 (AS, AF, EU, LATAM) Residential ESS – High Capacity & Scalable Solution

  • High Capacity: 125A, nominal voltage of 51.2V
  • Usable Energy: Offers 5.12 kWh at 90% depth of discharge (DoD)
  • Scalable Design: Supports up to 32 units in parallel
  • Wide Operating Range: Functions efficiently from -20°C to 55°C
  • Durability: IP65 rating for protection against dust and water
  • Smart Monitoring: Remote monitoring and upgrades for convenience
  • Safety Features: Built-in circuit breaker and intelligent BMS
  • Long Lifecycle: More than 6000 cycles for extended service life
  • Suitable Deye Inverter Model:
      • SUN-3/3.6/5/6K-SG04LP1-EU
      • SUN-3K-SG04LP1-EU-SM1
      • SUN-3.6/5/6K-SG04LP1-EU-SM2
      • SUN-3.6/5/6/7/7.6/8/10K-SG05LP1-EU
      • SUN-7/7.6/8/10K-5G05LP1-EU-SM2
      • SUN-12/14/16K-SG01LP1-EU
      • SUN-5/6/8/10/12K-SG04LP3-EU
      • SUN-3/4/5/6/8/10/12K-SG05LP3-EU-SM2
      • SUN-14/15/16/18/20K-SG05LP3-EU-SM2
SKU: RW-L5.1 (AS, AF, EU, LATAM)Categories: Low Voltage Series (LV)
Contact Us

Description

Introducing our advanced energy storage battery, a game-changer for your power needs.

Specification Details
Capacity 125A
Nominal Voltage 51.2V
Usable Energy 5.12 kWh (@ 90% DoD)
Charge/Discharge Current – Max Continuous 200A
Charge/Discharge Current – Peak 240A (10 seconds)
Dimensions 420 mm (W) x 680 mm (H) x 160 mm (D)
Weight Approximately 50 kg
Operating Temperature – Charge 0°C to 55°C
Operating Temperature – Discharge -20°C to 55°C
Cycle Life More than 6000 cycles
Installation Wall – mounted or floor – mounted options available
Warranty Period 10 years

Key Features

  • Flexible Configuration: It supports a maximum of 32 units in parallel, with a 10A current limit that’s compatible with any inverter for charging and discharging. Perfect for backup power and residential use.
  • Reliable Performance: Capable of max 1C charge and discharge, and a peak discharge current of 2C for 10 seconds. Housed in an IP65 case with natural cooling, it operates in a wide temperature range of -20°C to 55°C.
  • Convenient Operation: Features auto battery module networking (no DIP switches needed) and supports Deye remote monitoring and upgrade.
  • Safer & Smarter Design: Utilizes LFP battery with long lifespan and high efficiency. Equipped with a built – in circuit breaker and intelligent BMS.
With a capacity of 125A, nominal voltage of 51.2V, and usable energy of 5.12 kWh (@ 90% DoD), it offers max continuous charge/discharge current of 200A and peak 240A (10 seconds). Measuring 420 mm (W) x 680 mm (H) x 160 mm (D) and weighing approx 50 kg, it can be wall – mounted or floor – mounted. Boasting over 6000 cycles and a 10 – year warranty, it’s your reliable energy solution.

Download

Deye RW-L5.1 Datasheet EN

Deye RW-L5.1 Datasheet French

Deye RW-L5.1 User Manual EN

Deye RW-L+SUN-3.6-6-12K Energy Storage Solution EN

Certificate

CB_RW-L5.1_DSS_FI-65225

CE-EMC_RW-L5.1_DSS_SZEM2506005255BA Ver_CE

Statement

DEYE Statement on Battery Expansion and Insulation Fault
