RW-M6.1-B

RW-M6.1-B

For EU & AU

ModelRN-M6.1-B
Main Parameter
Battery ChemistryLiFePO4
Capacity (Ah)120
ScalabilityMax.32 pcs in Parallel(196kWh)
Nominal Voltage (V)51.2
Operating Voltage(V)43.2~57.6
Energy (kWh)6.14
Usable Energy (kWh)ⁿ6.14
Rated DC Power(kW)3.07
Charge/Discharge Current (A)ⁿRecommend 60
Max. 100
Peak(2mins,25℃) 150
Other Parameter
Recommend Depth of Discharge100%
Dimension (W×H×D, mm)510*740*145(Without Base, depth of 161mm with Hanging Board)
Weight Approximate(kg)58
Master LED Indicator5LED(SOC:20%~SOC100%,3LED(working, alarming, protecting)
IP Rating of EnclosureIP65
Operating TemperatureCharge:0~55℃(-20℃~55℃ when heating on) / Discharge:-20℃~55℃
Storage Temperature0℃~35℃
Humidity5%~95%
Altitude≤2000m
Cycle Life≥6000(25℃±2.0℃,0.5C/0.5C,70%EOL)
InstallationWall-Mounted, Floor-Mounted
Communication PortCAN2.0, RS485
Warranty Periodⁿ10 years
Energy Throughput20MWh@70%EOL
CertificationUN38.3, IEC62619, CE, CEI 0-21, VDE2510-50
