| Model | SE-F12 Lite | |
| Battery Chemistry | LiFePO4 | |
| Capacity﹙Ah﹚ | 235 | |
| Scalability | Max. 32 pcs in parallel | |
| Nominal Voltage (V) | 51.2 | |
| Operating Voltage (V) | 44.8 ~ 57.6 | |
| Nominal Energy (kWh) | 12.03 | |
| Charge Current﹙A﹚ | Recommend Max. Continuous Peak | 75 |
| Max. Continuous | 120 | |
| Peak | 180(10s) | |
| Discharge Current﹙A﹚ | Recommend Max. Continuous Peak | 75 |
| Max. Continuous | 140 | |
| Peak | 210(10s) | |
| Other Parameter | ||
| Depth of Discharge | 95% | |
| Dimension ( W × H × D ) (Without hanging board)(mm) | 400 x 594 x 233 | |
| Weight Approximate (kg) | 84 | |
| LED Indicator | LED ( SOC, working, protecting ) & Buzzer | |
| IP Rating of Enclosure | IP21 | |
| Operating Temperature | Charge :0~55°C/Discharge: -20~55°C | |
| Storage Temperature | 0℃~35℃ | |
| Relative Humidity | 95% (non-condensing) | |
| Altitude (m) | ≤3000 | |
| Cycle Life | ≥6000(70%EOL) | |
| Installation | Wall-Mounted, Floor-Mounted, Stack-Mounted | |
| Communication | CAN2.0,RS485,Bluetooth+APP | |
| Warranty Period | 5 Years / 10 Years The warranty period depends on the final installation site of the battery system. For more information, please refer to the warranty policy. |
|
| Energy Throughput | 37 MWh | |
| Certification | UN38.3, CE, CB | |
