WD-G12100 Lithium Iron Phosphate Battery
The WD-G12100 is a compact, high-reliability lithium iron phosphate (LiFePO₄) battery designed for RVs, marine equipment, and backup power setups. It balances performance and practicality, making it a top choice for both residential and light-commercial use.
| Parameter | Details |
|---|---|
| Model | WD – G12100 |
| Battery Chemistry | LiFePO₄ |
| Nominal Capacity | 100 Ah |
| Nominal Voltage | 12.8 V |
| Operating Voltage | 11.2 V ~ 14.6 V |
| Nominal Energy | 1.28 kWh |
| Cell Configuration | Prismatic, 1P4S |
| Scalability | Max 4 units in series (51.2 V) and Max 10 units in parallel |
| Charge Current | – Max. Continuous: 100 A – Peak: 200 A (10 sec) |
| Discharge Current | – Max. Continuous: 100 A – Peak: 200 A (10 sec) |
| Recommend Depth of Discharge | 80% DoD |
| Dimension Approximate (W×D×H, mm) | 310 × 160 × 298 |
| Weight Approximate | 11 kg |
| Case Material | ABS+PC |
| LED Indicator | LED (SOC, working, protecting) & Buzzer |
| Communication | RS485 |
| IP Rating of Enclosure | IP20 |
| Operating Temperature | – Charge: 0 – 55°C – Discharge: -20°C – 55°C |
| Storage Temperature | 0 – 35°C |
| Relative Humidity | 95% |
| Altitude | ≤2000m |
| Cycle Life | ≥6000 (25°C±2°C, 0.2C charging and discharging, 80% DoD, 70% EOL) |
| Warranty Period | 5 years |
| Installation | Floor – Mounted, Stack – Mounted |
| Certification | UN38.3, MSDS |
- Reliable Capacity & Energy: Delivers a nominal capacity of 100 Ah and nominal energy of 1.28 kWh, providing steady power for daily devices or emergency backup needs.
- Flexible Scalability: Supports up to 4 units in series (reaching 51.2 V) and 10 units in parallel, allowing users to customize power systems based on specific voltage and capacity requirements.
- Efficient Charging & Discharging: Features max continuous charge/discharge current of 100 A and 200 A peak current (10 sec), enabling fast energy replenishment and stable power output for high-demand devices.
- Long-Lasting Durability: Boasts ≥6000 charge-discharge cycles (under 25°C±2°C, 0.2C, 80% DoD, 70% EOL) and a 5-year warranty. It operates in a wide temperature range: 0-55°C for charging and -20-55°C for discharging, adapting to harsh environments.
- User-Centric Design: Weighs only 11 kg with dimensions 310×160×298 mm, making installation easy via floor or stack mounting. Equipped with LED indicators (SOC, working, protection status) and a buzzer, plus RS485 communication for firmware updates, ensuring convenient monitoring and maintenance.
