RW-F5.1-1H2 (EU)

Powerful Output: 5000W rated power with 2x peak output capacity (10 seconds)
High-Capacity Battery: Integrated 5.12kWh LiFePO₄ battery with >6000 cycles (70% EOL)
Quick Switching: Fast response time of ≤4ms for uninterrupted energy supply
Energy Efficiency: 97% max efficiency for optimized energy usage
Scalable Design: Expandable up to 16 units, supporting up to 163.8kWh (Low Voltage)
Smart Monitoring: Touch LCD display with Wi-Fi/Bluetooth control via app or PC
Durable Build: IP65-rated for indoor and outdoor use; operates in 0°C to 55°C
Easy Installation: Compact, wall-mounted or floor-mounted design for space-saving

SKU: RW-F5.1-1H2 Category: Low Voltage Series (LV)

Description

RW-F5.1-1H2 All-in-One Energy Storage Solution

The RW-F5.1-1H2 by Deye is an advanced, all-in-one energy storage system designed to bring optimized performance, seamless integration, and reliable energy management to residential settings. Combining cutting-edge technology with a sleek design, this unit guarantees safety, efficiency, and flexibility for energy storage and usage.

Key Features:

High Power Performance

Rated Power: Delivers 5000W of continuous output, ensuring stable energy supply.
Peak Output: Achieves 2 times the rated power for 10 seconds, perfect for handling sudden surges.
Battery Energy Configuration: Features a robust 5.12kWh LiFePO₄ battery, renowned for its safety, long cycle life, and performance.

Enhanced Reliability

Built-in Intelligent BMS (Battery Management System): Ensures complete battery protection and optimization.
Powerful Cooling & Protection: Operates efficiently under natural cooling with an IP65 protection rating, capable of withstanding temperatures between 0°C and 55°C and challenging environments.

Smart Applications

Supports peak-shaving, smart load management, AC coupling, and seamless operation with a rapid switching time of 4ms for reliable backup power.

Flexible Expansion

Scalable Design: Expandability up to 16 units in parallel, achieving a massive 81.9kWh (Low Voltage) or 80kWh (High Voltage) energy capacity.
Compatible with other Deye 5.12kWh LV batteries for system upgrades up to 163.8kWh.

Intelligent Control

Stay in control with a responsive Touch LCD display and connectivity via Wi-Fi or Bluetooth, enabling easy monitoring through an app or PC interface for complete energy transparency.

Simplified Installation

Compact, flat design allows wall-mounted or floor-mounted installation. Its modular construction ensures hassle-free setup, saving space and simplifying integration.

Technical Specifications at a Glance:

Category	Details
Rated Power	5000W
Battery Chemistry	LiFePO₄ (5.12kWh)
Max. Efficiency	97%
Switching Time	≤4ms
Cycle Life	>6000 cycles (70% EOL at 25°C)
Temperature Range	0°C to 55°C
IP Rating	IP65 (indoor & outdoor use)
Weight	71kg
Dimensions	616mm x 191mm x 690mm

Certifications and Safety

Compliant with global safety and performance standards: IEC/EN 62109-1, IEC 62619, UN38.3, and more.

The RW-F5.1-1H2 is ideal for homes requiring reliable energy storage, backup power during outages, or optimized energy usage in solar-powered systems. Its intelligent, fully-integrated design makes it suitable for both modern and traditional residential setups.

Future-proof your energy system with the RW-F5.1-1H2—efficient, expandable, and reliable.
