MS-G215-2H3

  • AC Power/Energy: 100 kW / 215 kWh
  • Scalable: Up to 20 units on-grid (2MW) or 10 units off-grid (1MW)
  • Safe: Features LFP batteries, aerosol fire extinguishing, and an explosion-proof design
  • Intelligent Control: Includes thermal management, load tracking, and peak-valley management
  • Reliable & Durable: Operates from -20°C to 50°C with IP54 & C5 protection
  • Long-Lasting: Rated for over 6000 cycles with a 10-year warranty
  • High Efficiency: Achieves a maximum efficiency of 97.6%
  • All-in-One: Fully integrated system with EMS, PCS, and BMS
SKU: MS-G215-2H3Categories: High Voltage Series (HV)
Contact Us

Description

Deye Winter MS Series: MS-G215-2H3 C&I Energy Storage Solution

The Deye Winter MS-G215-2H3 is a modular, grid-on/off battery energy storage solution designed for commercial and industrial applications. Combining LFP battery safety, intelligent energy management and robust power conversion, it delivers 100 kW/215 kWh per cabinet with industry-leading reliability, scalability and a 10-year warranty.

Parameter Value
AC Output Power 100 kW
AC Output Voltage & Frequency 380/400 Vac, 50/60 Hz
Grid Connection 3L / N / PE
Battery Voltage 660–864 V dc
Usable Energy 215 kWh
Round-Trip Efficiency 88 %
Dimensions (W × D × H) 1 865 × 1 000 × 2 500 mm
Weight (approx.) 2 700 kg
Operating Temp. –20 °C to 50 °C (derate > 45 °C)
Max. Altitude ≤ 3 000 m
Enclosure Rating IP54, C5 anti-corrosion
Communication Ethernet, 4G
Certifications UN3536, IEC61000, IEC62477, IEC60730
Warranty 10 years or ≥ 6 000 cycles (0.5C/0.5C, 25 °C, 70 % EOL)

Key Features:

  • High Power and Capacity: Delivers an AC output power of 100 kW with a total energy capacity of 215 kWh.
  • Massively Scalable: Easily expand your energy storage to meet demand. Support for up to 20 units in parallel for on-grid applications (maximum 2MW/4.3MWh) and up to 10 units for off-grid backup (maximum 1MW/2.15MWh).
  • Advanced Safety: Built with safety as a priority, the system utilizes stable LFP batteries. It features an integrated aerosol fire extinguishing system and a battery compartment with auto venting and explosion-proof design.
  • Intelligent Control: Sophisticated thermal management keeps the battery operating below 35°C. The system offers intelligent load tracking, peak-valley management, demand control, and backup power capabilities.
  • Superior Reliability & Durability:
    • Wide Operating Range: Functions in temperatures from -20°C to 50°C and at altitudes up to 3000m.
    • Robust Protection: Features an IP54 rating for enclosure protection and a C5 anti-corrosion grade, making it suitable for harsh environments.
    • Long-Lasting Performance: Guaranteed for >6000 cycles with a 10-year warranty.
    • High Overload Capacity: Can handle peak power of up to 1.1 times the rated power.
  • High Efficiency: The integrated converter boasts a maximum efficiency of 97.6%, minimizing energy loss.
  • Integrated Multi-Fusion System: Combines the EMS, PCS, and BMS into one seamless unit, with support for MPPT module expansion for a truly all-in-one solution.
  • Flexible Communication: Equipped with CAN, RS485, and Ethernet communication ports for easy integration and monitoring.

The MS-G215-2H3 delivers a high-performance, safe and scalable energy storage solution. Its robust thermal and overload protections, integrated control systems and long cycle life make it ideal for C&I users seeking reliable power quality, cost savings and a future-proof investment.
